C-One2 e-ID
All-in-one
ID verification
handheld
device
All-in-one ID verification handheld device
This product is no longer available…
MULTIPLE
Keypoints
All-in-one
Multipurpose device for ID verification
Quality
Rugged device derived from C-One product line
Security
High level of security for data captured and/or transmitted
Convenient
One hand operation, small and light weight
TECHNICAL
Specifications
IDENTIFICATION MODULES
| FINGERPRINT SCANNER | FAP30 acquisition | LES technology FAP30 certified | 500ppi | 256 grayscale dynamic range FBI certified Mobile ID | PIV 071006 | FAP30 | GSA FIPS201 |
| CAMERAS | 13 MPixels Autofocus & Flash light Sensor Sony IMX135 |
| MRZ READER | Compliant 9303 ICAO | Machine Readable Travel Documents | Accessory: left or right side |
| CONTACT/CONTACTLESS READER | Fully interoperable to read all types of e-ID documents Compliant with ISO 7816 1/2/3 (T=0 & T=1) 13.56 MHz | Elyctis | Compliant with ISO 14443 A / B standards |
| SECURE ELEMENTS | SAM socket Slot for external key integration |
PERFORMANCE
| OPERATING SYSTEM | Android 8 Supported by Coppernic in France |
| PROCESSOR | MSM 8956 | Dual Core @ 1.8 GHz | Quad Core @ 1.4 GHz |
| MEMORY | 2GB RAM LPDDR3 + 16 GB Flash eMMC Memory expansion – MicroSD slot– T-Flash: Up to 400GB |
PHYSICAL CHARACTERISTICS
| DIMENSIONS & WEIGHT | 211 mm x 90 mm x 42 mm – 550 grams | C-One2 e-ID with OCR : 211 mm x 119 mm x 55 mm – 630 grams |
| DISPLAY & TOUCH PANEL | 4.5’’ TFT LCD | 720×1280 | DragonTrail Glass | Touchscreen: Capacitive 5 Points Multi Touch |
| EXTERNAL PLUGS | Micro USB Pogo Pins |
| 3 300 MAH BATTERY | Non-Removable battery pack Charging Micro-USB / Docking station |
WIRELESS COMMUNICATIONS
| BLUETOOTH | Bluetooth LE 4.0 |
| WLAN | WiFi 802.11 a/b/g/n/ac – Direct – HotSpot |
| WWAN | 2G bands: GSM(850), EGSM(900), DCS(1800), PCS(1900) 3G bands: WCDMA Band 1,2,5,8 | 4G bands: LTE-FDD Band 1, 3, 5, 7, 8, 20, 28 |
| INTEGRATED GPS | GPS | A-GPS | GLONASS | BeiDou |
